What the chapter is about
When electric current flows through a wire, it does more than light a bulb. It produces heat, and it also produces magnetism. These two effects — the heating effect and the magnetic effect — are used in many devices around us.
The heating effect means a wire gets hot when current passes through it. This is how electric heaters, bulbs and fuses work. A fuse is a safety device: it is a thin wire that melts and breaks the circuit if too much current flows, protecting our appliances and homes.
The magnetic effect means a wire carrying current behaves like a magnet. If we wind wire into a coil around an iron nail and pass current through it, the nail becomes an electromagnet — a magnet we can switch on and off. Electromagnets are used in cranes, electric bells and motors.
What you should learn
Notice the heating effect and the magnetic effect of electric current, what a fuse does, and how an electromagnet is made and used.
Key Terms
- Electric current — The flow of electric charge through a conductor such as a wire.
- Heating effect — The production of heat when electric current flows through a wire.
- Magnetic effect — The production of magnetism around a wire carrying electric current.
- Electromagnet — A temporary magnet made by passing current through a coil wound around an iron core.
- Fuse — A safety device whose thin wire melts and breaks a circuit when the current is too high.
Remember
- Current flowing through a wire produces both heat and magnetism.
- A fuse melts and breaks the circuit to protect appliances from excess current.
- An electromagnet works only while current flows; switch off the current and its magnetism is lost.
- More turns in the coil or a stronger current makes a stronger electromagnet.
Exam Tip / Common Mistake
Common mistake: calling an electromagnet a permanent magnet. It is temporary — its magnetism appears when current flows and disappears when the current is switched off.
Chart / Table: Effects of electric current
| Point | Detail |
|---|---|
| Heating effect | Wire gets hot; used in heaters, bulbs, fuses |
| Magnetic effect | Current-carrying wire acts like a magnet |
| Electromagnet | Coil + iron core + current; can be switched on and off |
| Fuse | Thin wire melts on excess current; breaks the circuit |
| Uses | Electric bell, crane, motor, heater, bulb |
Practice set — try it yourself
- What is the heating effect of electric current?
Hint: Think about what happens to a wire when current flows. - Why is a fuse used in a circuit?
Hint: Think about safety when current is too high. - How can you make an electromagnet?
Hint: Think of a coil, an iron nail and a battery. - What happens to an electromagnet when the current is switched off?
Hint: Think about temporary magnetism. - Name two devices that use electromagnets.
Hint: Think of bells and lifting machines.
Questions with Answers
- What is the heating effect of electric current? Give an example.
When electric current flows through a wire, the wire becomes hot. This is the heating effect. It is used in electric heaters, toasters and the filament of a bulb, which glows because it gets very hot. - How does a fuse protect a circuit?
A fuse contains a thin wire that melts easily. If the current becomes too high, the fuse wire melts and breaks the circuit, so current stops flowing and the appliances and wiring are protected from damage. - How is an electromagnet made?
Wind insulated copper wire into a coil around an iron nail and connect the ends to a battery. When current flows, the nail becomes magnetic and can attract iron objects. It is an electromagnet. - How is an electromagnet different from a bar magnet?
A bar magnet is always magnetic. An electromagnet is magnetic only while current flows through its coil; switching off the current removes its magnetism, and its strength can be changed. - Why does a compass needle deflect near a current-carrying wire?
A current-carrying wire produces a magnetic field around it. The compass needle, which is itself a small magnet, turns in response to that field, showing the magnetic effect of electric current.
